Crushing and Screening-Hongxing Machinery(HXJQ)

The Handling Materials of Crushing and Screening:

Crushing and screening plants are for limestone, silica, dolomite, wind fossils, coal gangue, coal. shale, gypsum, etc.

mobile_crusher

The Function and Benefits of Crushing and Screening:

Crushing and screening is very convenient and flexible. Stone can be easily transferred from one location to another, the raw materials can be broken around this place without being transported again, and mobile crusher also can be moved with the promotional exploitation of the raw material. So crushing and screening can save lots of money and energy.

mobile_crusher

The Performance Characteristics of Crushing and Screening:

1. A complete line: all the machines are installed on the trailer, saves the occupation space, enhances the working efficiency.

2. Strong flexibility: it can be moved from one place to another place;

3. High efficiency.

4. Works well and easy maintenance.

Technical Parameter

MTN tire type mobile crushing and screening station

Series	Standard Model	On board equipment	On board equipment	Processing Capability (t/h)	Transport dimensions (mm)
MOBILE COARSE CRUSHING STATION	MTN96	GZDT9538	CJ96	70-200	13000x2950x4250
	MTN98	GZDT9538	HDX98	80-200	13000x2950x4250
	MTN106	GZDT1145A	CJ106	90-300	14000x3000x4400
	MTN110	GZDT1145A	HDX110	120-300	14000x3000x4400
	MTN1213C	GZDT9538	CI1213	80-200	13000x2950x4250
	MTN1316C	GZDT1145A	CI1316	100-300	14000x3000x4400
MOBILE MEDIUM AND FINE CRUSHING STATION	MTN300	-	HPM300C1	100-200	15500x2900x4200
	MTN400	-	HPM400C3	150-300	16500x3100x4300
	MTN250	-	SC250F1	90-200	16500x3100x4300
	MTN1213	-	CI1213	80-200	16000x2900x4300
	MTN1316	-	CI1316	100-300	16500x3100x4500
	MTN0926	-	HVI0926	85-200	16500x3100x4300
	MTN1040	-	HVI1040	120-300	16500x3100x4400
MOBILE SCREENING STATION	MTN1865-3	-	3HX1865	65-200	14500x2900x4000
MOBILE SCREENING STATION	MTN2165-3	-	3HX2165	85-300	15000x2900x4400
MOBILE STATION FOR MEDIUM AND FINE CRUSHING AND SCREENING	MTN300S-3SII	3HX1865	HPM300C1	100-200	15000x3000x4000
	MTN300S-3	3HX2165	HPM300C1	100-200	15000x3000x4000
	MTN400S-3	3HX2165	HPM400C3	150-300	15000x3000x4000
	MTNG400S-3SII	3HX1865	GYS400C1	100-200	15000x3000x4000
	MTNG400S-3	3HX2165	GYS400C1	100-200	15000x3000x4000
	MTN250S-3	3HX2165	SC250F1	90-200	15000x3000x4200
	MTN1213S-3	3HX1865	CI1213	80-200	15000x3000x4200
	MTN1316S-3	3HX2165	CI1316	100-300	15000x3000x4200
	MTN0926S-2	2HX1865	HVI0926	85-200	18000x3000x4200
	MTN1040S-2	2HX2165	HVI1040	120-300	18000x3000x4200
THREE COMBINATION MOBILE STATION	MTN1213-III	GZDT9538/3HX1865	CI1213	80-200	18200x2800x4350
	MTN1316-III	GZDT1145A/3HX2165	CI1316	100-300	18200x3000x4200
	MTN1410-III	GZDT9538/3HX1865	PCZ1410	80-200	18200x2800x4200
	MTN1612-III	GZDT1145A/3HX2165	PCZ1612	100-300	18200x3000x4200
FOUR COMBINATION MOBILE STATION	MTN100Y-2	GZD850X3000/2YK1545	HD72/GYS300	50-100	15000x2650x4500
	MTN100Y-3	GZDT0835/3HX1548	HDX86/SC100F1	50-100	17500x2500x4000
	MTN150Y-3	GZDT0835/3HX1548	HDX86/SC160F1	70-150	17500x2500x4000
	MTN150R-3	GZDT0835/3HX1548	HDX86/CI1110	60-150	17500x2500x4000
